Hydraulic climbing conveyor

Features and advantages
Anti-slip & Stable Climbing
Durable & Corrosion-resistant
Flexible & Adaptable
Easy to Clean & Safe

Product Overview
1.Basic Parameters
Material: PVC (Food-grade / FDA certified optional)
Specifications: Thickness 2-5mm, Width 300-1500mm (Customizable)
Conveying Inclination: 15°-45° (Special angles customizable)
Surface Texture: Diamond / Striped / Plain (Optional)
Tensile Strength: ≥15MPa, Operating Temperature: -10℃~60℃
Joint: Heat-sealed / Mechanical Joint (Firm & Flat)
2. Core Structure & Features
Structure: PVC Surface Layer + Polyester Fiber Tensile Layer + Bottom Layer (Balances anti-slip performance and load-bearing capacity)
Features: Weight 2.5-3.5kg/㎡, Low noise; Anti-static & UV-resistant optional; High customization level

Relevant Parameters


Applicable Scenarios
1. Applicable Industries
Food, Daily Chemicals, Electronics, Logistics & Warehousing, Manufacturing (Climbing Conveyance, Process Connection, Sorting & Transfer)
2. Operation & Maintenance Points
Installation: Proper tension, flat joints, close fit with rollers/idlers
Operation: Do not convey sharp/overweight materials; Match speed with inclination
Maintenance: Regular cleaning, inspect joints and wear; Avoid direct sunlight, high temperature and corrosive substances
