Food-Grade PVC Modular Cleated Incline Conveyor | Vertical Elevator for Fruit Vegetable Processing Line
Adopts food-grade PVC modular belt, safe, non-toxic and easy to clean
Cleated climbing design, stable vertical or inclined material conveying
Modular assembly structure, flexible layout and simple maintenance
Adjustable conveying speed & height, adaptable to various production lines
Stainless steel frame, corrosion-resistant and hygiene-compliant for food industry
- Overview
- Recommended Products
Product Features & Advantages
High sanitation standard, meets food processing safety requirements
Anti-slip cleats prevent fruits, vegetables and granular materials from slipping back
Compact structure, saves workshop space for vertical transportation
Low noise, stable operation and long service life
Easy disassembly & cleaning, avoids material residue and bacterial growth
Product Parameters
| Item | Specification |
| Conveyor Belt Material | Food-grade PVC Modular Belt |
| Frame Material | 304 Stainless Steel |
| Conveying Angle | 0°–90° adjustable |
| Conveying Speed | 0.5–6 m/min (variable frequency adjustable) |
| Conveying Height | Customized 1–8 m |
| Belt Width | 100–800 mm customized |
| Motor Power | 0.55–3 kW |
| Voltage | 380V/220V, 50Hz/60Hz |
| Application | Fruit, vegetable, food raw material vertical/inclined conveying |
Product Description
This food-grade PVC modular cleated incline conveyor is specially designed for fruit and vegetable processing and vertical material transportation. Equipped with food-safe PVC modular belts and antislip cleats, it effectively prevents materials from sliding during climbing and vertical lifting.
